Actuating radii The axis of the hinge should be x mm above the top edge
of the safety switch and in the same plane.
a = Actuating radius to the plane of the actuator
b = Actuating radius in line with the plane of the actuator
x = Axial misalignment

Attention! x must be referred to the surface of the enclosure and not to the inserted actuator!

Accessories for ES 14 AZ Extreme / Ex 14 AZ

Actuator for ES/Ex 14 AZ

Article no.: 1179003 Old article no.: 02.14.6801

contact us

Product features

  • Stainless steel actuator

  • Actuating radius on hinged lift cabin/shaft doors
    a = 100 mm and b = 100 mm

  • Axial misalignment x = 2.5 mm
